General




Physical dimensions

12.5" x 7.3" x 2.7" (318 x 185 x 69 mm)



Weight


4.1 lbs (1.85 kg)




Water rating

IPX7



Display type

WSVGA display



Display size

8.8" x 4.9" (224 x 125 mm)



Display resolution

1024 x 600 pixels



Power consumption


Max power usage at 10 Vdc: 32.4 W

Typical current draw at 12 Vdc: 1.9 A

Max current draw at 12 Vdc: 2.7 A




Antenna

Internal or external over NMEA 2000



Mounting options

Bail or flush



Receiver

10 Hz high-sensitivity



Garmin Marine Network™ ports


2









Maps & Memory




Accepts data cards

2 SD™ cards



Waypoints

5,000



Routes

100



Track log

50,000 points; 50 saved tracks



Preloaded maps


BlueChart® g2 (US and Western Canada coastal maps) and LakeVü HD (inland maps)









Outdoor Recreation Features




Tide tables










Chartplotter Features




Garmin Radar compatible





Garmin Sonar compatible


Yes (built-in)




Garmin SmartMode compatible (customizable monitor presets)





Supports AIS (tracks target ships position)





Supports DSC (displays position data from DSC-capable VHF radio)





Garmin Meteor™ Audio System compatible





Supports FUSION-Link™ compatible radios





GSD™ Black Box sonar support





GCV™ Black Box sonar support





ActiveCaptain compatible





Garmin Helm compatible





GRID™ (Garmin Remote Input Device) compatible





Wireless remote compatible










Sonar Features & Specifications




Dual-frequency (50/200 kHz) sonar capable





Dual-beam (77/200 kHz) sonar capable





Transmit power

1 kW traditional; 1 kW single channel CHIRP



CHIRP sonar technology

Yes (Built-in)



ClearVü

Yes with CHIRP (built-in)



SideVü


Yes with CHIRP (built-in)




Maximum depth

5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions)



Bottom lock (shows return from the bottom up)





Water temperature log and graph





Sonar recording





Sonar history rewind
