CPU
Intel? Socket LGA1700 for 13th Gen Intel? Core. Processors e 12th Gen
Intel? Core., Pentium? Gold and Celeron? Processors*


Supports Intel? Turbo Boost Technology 2.0 and Intel? Turbo Boost Max
Technology 3.0**


* Refer to www.asus.com for CPU support list.


** Intel? Turbo Boost Max Technology 3.0 support depends on the CPU
types.
Chipset
Intel? B660 Chipset

Memory
2 x DIMM, Max. 64GB, DDR5 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/
5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory*


Dual Channel Memory Architecture


Supports Intel? Extreme Memory Profile (XMP)


OptiMem II


* Supported memory types, data rate(Speed), and number of DRAM module
vary depending on the CPU and memory configuration, for more
information refer to www.asus.com for memory support list.


* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

Graphics
1 x DisplayPort**


1 x HDMI?***


* Graphics specifications may vary between CPU types. Please refer to
www.intel.com for any updates.


** Support 4K@60Hz as specified in DisplayPort 1.4


*** Support 4K@60Hz as specified in HDMI 2.1.

Expansion Slots
Intel? 13th e 12th Gen Processors*


1 x PCIe 5.0 x16 slot

Storage
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports


Intel? 13th e 12th Gen Processors*


M.2_1 slot (Key M), type 2260/2280 (supports PCIe 4.0 x4 mode)


Intel? B660 Chipset**


M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)


4 x SATA 6Gb/s ports****


* Intel? Rapid Storage Technology supports SATA RAID 0/1/5/10.


** Intel? Rapid Storage Technology supports Intel? Optane Memory H
Series on PCH attached M.2 slots.

Ethernet
1 x Intel? I225-V 2.5Gb Ethernet


ASUS LANGuard

Wireless e Bluetooth
Wi-Fi 6


2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)


Supports 2.4/5GHz frequency band


Bluetooth v5.2

USB
Rear USB (Total 8 ports)


1 x USB 3.2 Gen 2x2 port (1 x USB Type-C?)


4 x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C?)


3 x USB 2.0 ports (3 x Type-A)


Front USB (Total 5 ports)


1 x USB 3.2 Gen 2 connector (supports USB Type-C?)


1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports


1 x USB 2.0 header supports additional 2 USB 2.0 ports

Audio
"ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A


- Impedance sense for front and rear headphone outputs


- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking


- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input (Line-in)


- Supports up to 32-Bit/192 kHz playback*"


Audio Features


- SupremeFX Shielding Technology


- Savitech SV3H712 AMP


- Premium audio capacitors


- Due to limitations in HAD bandwidth, 32-Bit/192 kHz is not supported
for 7.1 Surround Sound audio.
