PROCESSOR
Supports 12th Gen Intel? Core. Processors, Pentium? Gold and Celeron?
Processors1

Processor socket LGA1700

Please go to www.msi.com to get the newest support status as new
processors are released.
See supported processors

CHIPSET
Intel? H610 Chipset

MEMORY
2x DDR4 memory slots, support up to 64GB1
Supports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC e POR)
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Please refer to www.msi.com for more information on compatible memory.
See supported memory

EXPANSION SLOT
1x PCIe x16 slot (From CPU)
Supports up to PCIe 4.0 x16
1x PCIe x1 slot
Supports PCIe 3.0 x1
1x M.2 slot with E-key for PCIe WiFi module only (M2_ WIFI1)
ONBOARD GRAPHICS
1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz 1 2
1x VGA port, supports a maximum resolution of 2048x1536 50Hz, 2048x1280
60Hz, 1920x1200 60Hz1
x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1 2
Available only on processors featuring integrated graphics. Graphics
specifications may vary depending on the CPU installed.
SATA PORTS
4x SATA 6Gb/s ports1
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1
slot.
M.2 SSD SLOT
1x M.2 slot (Key M, from chipset)1
Supports up to PCIe 3.0 x4
Supports up to SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
Supports Intel? Smart Response Technology for Intel Core. processors
SATA7 will be unavailable when installing M.2 SATA SSD in the M2_1
slot
USB
Intel? H610 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports
available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports
available through the internal USB 2.0 connector)
AUDIO
Realtek? ALC892/ ALC897 Codec
7.1-Channel High Definition Audio
LAN
1x Intel? I219V 1Gbps LAN controller
POWER CONNECTORS
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
FAN CONNECTORS
1x 4-pin CPU fan connector
1x 4-pin system fan connector
SYSTEM CONNECTORS
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
JUMPERS
1x Clear CMOS jumper
LED FEATURES
1x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
4x EZ Debug LED
BACK PANEL PORTS
HDMI
VGA
DisplayPort
Keyboard/Mouse
USB 3.2 Gen 1 5Gbps Type-A
LAN port
Audio connector
USB 2.0
