CPU
Intel? Socket 1200 for 10th Gen Intel? Core., Pentium? Gold and
Celeron? Processors *
Supports Intel? 14 nm CPU
Supports Intel? Turbo Boost Technology 2.0 and Intel? Turbo Boost Max
Technology 3.0**
* Refer to www.asus.com for CPU support list
**Intel? Turbo Boost Max Technology 3.0 support depends on the CPU
types.
Chipset
Intel? B460
Memory
4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC,
Un-buffered Memory *
Dual Channel Memory Architecture
Supports Intel? Extreme Memory Profile (XMP)
OptiMem
* 10th Gen Intel? Core.i9/i7 CPUs support 2933/2800/2666/2400/2133
natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors
Lists).
Graphic
Integrated Graphics Processor
1 x DisplayPort 1.4 **
1 x HDMI 1.4b
1 x DVI-D
*Graphics specifications may vary between CPU types.
**Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.
Please refer to www.intel.com for any update.
Multi-GPU Support
Supports AMD 2-Way CrossFireX Technology
Expansion Slots
Intel? 10th Gen Processors
1 x PCIe 3.0 x16 (x16 mode)
Intel? B460 Chipset
1 x PCIe 3.0 x16 (x4 mode)
1 x PCIe 3.0 x1
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel? B460 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices
support (SATA e PCIE 3.0 x 4 mode)*1
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices
support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel? Rapid Storage Technology supports
Intel? Optane. Memory Ready *2
LAN
Intel? I219-V 1Gb Ethernet
Wireless Data Network
Intel? Wi-Fi 6 AX200
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max data rate
Supports dual band frequency 2.4/5 GHz
Supports channel bandwidth: HT20/HT40/HT80/HT160
Supports PCIe interface
Bluetooth
Bluetooth v5.1*
*BT 5.1 function will be ready in Windows 10 build 19041 or later.
Audio
Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC *
- Supports : Jack-detection, Multi-recording, Front Panel
Jack-retasking, up to 24-Bit/192kHz playback
Audio Feature :
- Exclusive DTS Custom for GAMING Headsets.
- Audio cover
- Audio Shielding
- Dedicated audio PCB layers
- Premium Japanese audio capacitors
* Choose the chassis with HD audio module in front panel to support
8-channel audio output.
USB Ports
Rear USB Port ( Total 6 )
4 x USB 3.2 Gen 1 port(s)
2 x USB 2.0 port(s)(2 x Type-A)
Front USB Port ( Total 6 )
2 x USB 3.2 Gen 1 port(s)
4 x USB 2.0 port(s)
